InvisiCore | Professional Indoor Products Linear LED Profile

The InvisiCore Series represents the absolute pinnacle of large-scale commercial linear lighting, engineered to create sweeping, expansive paths of light that vanish completely into false ceiling architectures. Boasting a massive 90 mm wide top flange, a 33.5 mm depth, and a wide 75 mm internal channel, this heavy-duty profile is purpose-built to house high-performance multi-row LED arrays. Extruded from top-tier structural aluminum to manage intensive heat loads effortlessly, it can be ordered in custom sizes and RAL-matched powder-coated or anodized finishes to deliver massive illumination across vertical or horizontal planes.

The series employs a premium wide-format PMMA diffuser available in Opal, Frosted, or Milky options, turning raw, high-intensity output into a perfectly uniform, glare-free 120-degree light distribution. Offering ultimate creative freedom for large public spaces, InvisiCore supports classic white color temperatures from 2200K to 6500K, alongside integrated Tunable White, RGB, RGBW, and RGBWW dynamic color systems. Scaling from a soft 4.5W up to a powerful 39.5W per meter and backed by IP40/IP54 ratings, it is the definitive architectural selection for seamless drywall integration, continuous long-run recess systems, architectural ceiling grooves, and minimal spatial lighting in premium corporate offices and corporate lobbies. Tailored structural end caps and heavy-duty mounting accessories provide an impeccably tight, premium installation every time.
